Battery
Capacity3000 mAh
Wireless ChargingYes
Wireless Charging StandardsWPC, PMA
Talk Time1320 minutes
Standby Time326 hours
Run Time DetailsTalk (3G): up to 1320 min Active online usage (Wi-Fi): up to 14 hrs Active online usage (3G): up to 11 hrs Active online usage (LTE): up to 12 hrs Playback (audio (Always On Display Off)): up to 80 hrs Playback (audio (Always On Display On)): up to 48 hrs Playback (video): up to 16 hrs Standby (AOD off): up to 326 hrs Standby (AOD on): up to 80 hrs
Cellular
TechnologyTD-SCDMA / WCDMA (UMTS) / GSM
Mobile Broadband Generation4G
Service ProviderNot specified
Operating SystemAndroid 8.0 Oreo
Intelligent AssistantBixby
NavigationGPS, GLONASS, BeiDou, Galileo
SIM Card TypeNano SIM
SIM Card Slot QtyDual-SIM (SIM1 and SIM2/MicroSD slots)
SIM Card Configuration DetailsNano SIM + nano SIM/microSD
Payment TechnologySamsung Pay
Input DeviceMulti-touch, capacitive
Communications
Data TransmissionGPRS, EDGE, HSDPA, HSUPA, HSPA+, VoLTE, FDD-LTE, TDD-LTE, VoWiFi
2G BandGSM 850/900/1800/1900 / TD-SCDMA
3G UMTS BandBand 1, Band 2, Band 4, Band 5, Band 8
3G UMTS Frequency2100, 1900, 1700, 850, 900
4G LTE BandBand 1, Band 2, Band 3, Band 4, Band 5, Band 7, Band 8, Band 12, Band 13, Band 17, Band 18, Band 19, Band 20, Band 25, Band 26, Band 28, Band 32, Band 38, Band 39, Band 40, Band 41, Band 66
4G LTE FrequencyFDD 2100, FDD 1900 PCS, FDD 1800+, FDD 1700 - 2110 AWS, FDD 850, FDD 2600, FDD 900, FDD 700a, FDD 700c, FDD 700b, FDD 800 lower, FDD 800 upper, FDD 800 DD, FDD 1900+, FDD 850+, FDD 700 APT, FDD 1500 L, TDD 2600, TDD 1900, TDD 2300, TDD 2500, FDD 1700 - 2110 AWS-3
Wireless InterfaceNFC, IEEE 802.11a/b/g/n/ac, Bluetooth 5.0 LE, ANT+/ANT
Bluetooth ProfilesHFP, HSP, OPP, PAN, A2DP, AVRCP, HID, PBAP, MAP, HOGP, BLE
Connections
Connector TypeUSB Type-C - 24 pin USB-C Headset jack - mini-phone 3.5 mm
Display
TypeOLED display
TechnologyQuad HD+ Super AMOLED
Diagonal Size5.8"
Display Resolution2960 x 1440 pixels
Display FormatQHD+
Pixel Density570 ppi
Aspect Ratio18.5:9
Color Depth16.7 million colors
HDRYes
ProtectionCorning Gorilla Glass 5 (scratch resistant glass)
FeaturesAlways-on display, Edge Screen, Infinity Display
Environmental Parameters
Max Depth of Water Resistance5 ft
Front Camera
Sensor Resolution8 Megapixel
Sensor TypeCMOS
Sensor Size1/3.6"
Lens ApertureF/1.7
Focus AdjustmentAutomatic
Special EffectsHDR, Grid Line
Camera ModesTimer mode, wide selfie mode, selfie mode, AR Emoji, selfie focus
FeaturesQuick launch, Motion photo, Stamps, location tags, VDIS (Video Digital Image Stabilization)
General
Product TypeSmartphone
Form FactorTouch
ProtectionDustproof, splashproof, waterproof
Integrated ComponentsRear-facing camera, front-facing camera, voice recorder, stereo speakers, navigation, digital player
Width2.7 in
Depth0.3 in
Height5.8 in
Weight5.75 oz
Body ColorCoral blue
Body MaterialMetal frame
SAR Value1.18 W/kg (body) / 0.362 W/kg (head)
Graphics System
Graphics AcceleratorMali-G72 MP18
Media Player
Supported Digital Audio StandardsWAV, WMA, AAC, PCM, AMR, MP3, FLAC, AAC-LC, XMF, AAC +, OGG, eAAC+, MIDI, APE (Monkey's Audio), M4A, apt-X, DSF, DSD, MXMF, OGA, 3GA, AWB, IMY, RTTTL, RTX, OTA, OPUS, DFF, MID, AMR-WB, AMR-NB, Vorbis, DSD64, DSD128
Supported Digital Video StandardsMKV, VC-1, FLV, AVC, AVI, MPEG-4, WMV, ASF, 3GP, H.264, H.263, M4V, WebM, HEVC, MP43, 3G2, WMV8, VP8, VP9, H.265, WMV7
Sound EnhancementsDolby Digital Plus sound, Dolby Atmos sound technology, Surround sound, stereo speakers tuned by AKG, Dolby Digital sound
Memory
RAM4 GB - LPDDR4 SDRAM
Internal Memory Capacity64 GB
User Memory50.3 GB
Supported Flash Memory CardsmicroSDXC - up to 400 GB
Messaging & Internet
Messaging ServicesSMS, MMS
Supported Social Networks and BlogsYes
Miscellaneous
Compliant StandardsIP68
Included AccessoriesPower adapter, SIM card removal tool, USB Connector (USB-C), micro-USB connector, USB-C cable, headset (tuned by AKG)
Phone Features
Phone FunctionsSpeakerphone, voice control, call timer, conference call, flight mode, voice dialing, vibrating alert
SensorsAccelerometer, proximity sensor, barometer, gyro sensor, hall sensor, RGB sensor, heart rate, pressure sensor, geomagnetic sensor
Security DevicesFingerprint reader, eye scan, face recognition
Additional FeaturesMultitasking, Face Unlock, Wi-Fi Miracast, Multi Window, MU-MIMO technology, Fast Charging, Samsung KNOX, High AOP Mic, Samsung DeX support, Bixby Vision, Intelligent Scan
Processor
TypeSamsung Exynos
Processor Number9810
Clock Speed2.7 GHz
Processor Core Qty8-core
64-bit ArchitectureYes
Rear Camera
Sensor Resolution12 Megapixel
Sensor Size1/2.55"
Optical Image StabilizerOptical Image Stabilizer (OIS)
Lens ApertureF/1.5 & f/2.4
Focus AdjustmentAutomatic, manual
Digital Zoom8
Self-Timer DelayYes
Special EffectsMotion Effect, HDR, Stamp, Bokeh effect, Grid Line, Stickers
Camera ModesPanorama, Pro mode, Timer mode, HYPERLAPSE, Auto mode, low-light shots, Food mode, Super Slow-mo, AR Emoji
Face DetectionFace detection
White BalanceCustom, automatic
Light SourceLED flash
Video Resolutions1920 x 1080 (1080p) at 30 fps, 1920 x 1080 (1080p) at 60 fps, 1280 x 720 (720p) at 30 fps, 3840 x 2160 (4K) at 30 fps, 3840 x 2160 (4K) at 60 fps, Super slow motion video 1280 x 720 (720p) at 960 fps, Slo-mo video 1920 x 1080 (1080p) at 240 fps, 2560 x 1440 (QHD) at 30 fps
FeaturesSelective Focus, Quick Launch, Playback zoom, Tracking Focus, Motion photo, Exposure, Shutter speed, geotagging, Continuous Auto Focus (CAF), RAW image capture, VDIS (Video Digital Image Stabilization), High CRI LED flash, Tracking AF, Stamps, location tags, Hyperlapse video support 1080p, Live focus with bokeh filters, Super Speed Dual Pixel
Universal Product Identifiers
BrandSamsung
Part NumberSM-G960FZBDXEF
GTIN08801643151959
